OMRON G5V- 2 DPDT 12VDC $1.50ea Spec's

Omron realys G5V-1 12Vdc SPDT $0.99ea







Semiconductors

Sanyo STK4040 II Amp Module70 Watt $5.95 ea

Data Sheet

















Sanyo STK 4038 II Amp Module 60 Watt $4.95ea

Data Sheet



Part Number

Package

Description

Price Each

100s


Fairchild NE 5532



Op-Amp

$0.39



National LM 3914N



Dot/Bar Display Driver

$0.99



7805

TO220

5V Regulator

$0.40

$35.00

7812

TO220

12V Regulator

$0.40

$35.00

LM 3886T



68W power amp chip

$4.50



LM317T

TO220

Variable Regulator

$0.50

$45.00

Tip 31C

NPN

100v 3A Transistor

$0.40

$35.00

Tip 33C

NPN

100v 10A Transistor

$0.60

$55.00

Tip 34C

PNP

100v 10A Transistor

$0.60

$55.00

Tip 36C

PNP

100v 25A Transistor

$0.60

$50.00

Tip 145

PNP

60v 10a Darlington

$1.00



TIP 2955

PNP

100V 15A

$0.79

$75.00

MJ10051

NPN

850v Darlington 50A image

$3.95



IRF 9630

TO220

Mosfet P Channel

$0.49



IN 5408   1000PIV 3A Axial lead Diode
$0.12
$10.00





600 P.I.V. 25A 1" x 1" 1/4" Tab Terminal Bridge

$2.50



W005M



3/8" Round 50 P.I.V. 1A Bridge

$0.39



NE555N



Timer

$0.39

$35.00

TDA 1519



2X 6W Power Chip

$0.79




Relays

Manufacturer

Part Number

Description

Price Each


American Zettler

AZ8352C6DEA

6 VDC DPDT Mininature

$1.00

American Zettler

AZ7P-6C-6D

6 VDC 6PDT Flat PC Mount

$2.50

Goldstar

VS12MBNR

12 VDC SPST T.V. Relay

$2.00

American Zettler

AZ733-12D

12 VDC DPDT 10a PC Mount

$2.00

DIP Socket

FBR244D024/2CE

24 VDC DPDT DIP

$2.00




Machine IC Sockets

Number of Pins

Price Each


14 pin

$0.28

16 pin

$0.32

28 pin

$0.50
